Specifications Camera Image Sensor: 1/3" Progressive Scan CMOS Min. Illumination: Color - 0.003 Lux @ (F1.4, AGC ON), B/W - 0 Lux with IR Shutter Speed: 1/3 s to 1/100,000 s Slow Shutter: Yes P/N: P/N Wide Dynamic Range: 120 dB Day & Night: IR cut filter Angle Adjustment: Pan - 0° to 355°, Tilt - 0° to 90°, Rotate - 0° to 360° Power-Off Memory: Yes Max. Resolution: 2688 × 1520 Lens Lens Type: Varifocal lens, motor-driven lens, 2.8 to 12 mm Iris Type: Fixed Focal Length & FOV: 2.8 to 12 mm, Horizontal FOV - 108° to 30°, Vertical FOV - 56° to 17°, Diagonal FOV - 131° to 35° Aperture: F1.4 Lens Mount: Ø14 DORI: 2.8 to 12 mm - Wide: D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m, Tele: D: 190 m, O: 75.4 m, R: 38.0 m, I: 19.0 m Illuminator Supplement Light Type: IR IR Range: Up to 60 m IR Wavelength: 850 nm Smart Supplement Light: Yes Visual Alarm: Yes Supplement Light Range: Up to 60 m Video Max. Resolution: 2688 × 1520 Main Stream: 50 Hz - 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720), 60 Hz - 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream: 50 Hz - 25 fps (1280 × 720, 640 × 480, 640 × 360), 60 Hz - 30 fps (1280 × 720, 640 × 480, 640 × 360) Third Stream: 50 Hz - 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), 60 Hz - 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) Video Compression: Main stream - H.265/H.264/H.265+/H.264+ Sub-stream - H.265/H.264/MJPEG Third stream - H.265/H.264 Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile H.264+ and H.265+ encoding Region Of Interest (ROI): 1 fixed region for main stream and sub-stream Audio Environment Noise Filtering: Yes Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Network Simultaneous Live View: Up to 6 channels API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets User/Host: Up to 32 users. 3 user levels: administrator, operator, and user Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Client: iVMS-4200, Hik-Connect, Hik-Central Web Browser: Plug-in required live view - IE 10, IE 11, Plug-in free live view - Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service - Chrome 57.0+, Firefox 52.0+, Edge 89+ Image SNR: ≥ 52 dB Day/Night Switch: Day, Night, Auto, Schedule Image Enhancement: BLC, HLC, 3D DNR Image Parameters Switch: Yes Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Wide Dynamic Range (WDR): 120 dB Interface Alarm: 1 input, 1 output (max. 12 VDC/24 VAC, 1 A) Audio: 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), 3.5 mm terminal block, output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, Built-In Microphone: Yes Built-In Speaker: Power - 2 W. Max. sound pressure level: 10 cm - 97 dB On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Hardware Reset: Yes Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Event Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exceptio Smart Event: Scene change detection Linkage: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning Deep Learning Function: Face Capture Perimeter Protection: Line crossing detection, intrusion detection, region entrance detection, region exiting detection General Linkage Method: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning Web Client Language: 33 languages General Function: Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter Software Reset: Yes Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Power Supply: 12 VDC ± 25%, reverse polarity protection, PoE: 802.3at, Class 4 Power Consumption And Current: 12 VDC, 1.21 A, max. 14.5 W, PoE (802.3at, 42.5 V to 57 V), 0.43 A to 0.32 A, max. 18 W Power Interface: Two-core terminal plug Camera Dimension: Ø144 mm × 342.6 mm (Ø5.7" × 13.5") Package Dimension: 385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1") Camera Weight: Approx. 1355 g (3.0 lb.) With Package Weight: Approx. 2011 g (4.4 lb.) Power: 12 VDC ± 25%, 1.21 A, max. 14.5 W, Two-core terminal plug, reverse polarity protection, PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.43 A to 0.32 A, max. 18 W Language: 33 languages - English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Approval: EMC - FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Safety - UL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 ); CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 ); LOA (IEC/EN 60950-1) Environment - CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Protection - IP66 (IEC 60529-2013), IK 10 (IEC 60529-2013)
